Kerberos

Note

Kerberos per RFC4120 + RFC6113 (FAST)

High-Level

Scapy includes a (tiny) kerberos client, that has basic functionalities such as:

AS-REQ

Note

Full doc at krb_as_req(). krb_as_req actually calls a Scapy automaton.

>>> res = krb_as_req("user1@DOMAIN.LOCAL", "192.168.122.17", password="Password1")

This is what it looks like with wireshark:

../_images/wireshark_asreq.png

The result is a named tuple with both the full AP-REP and the decrypted session key:

>>> res.asrep.show()
###[ KRB_AS_REP ]###
    pvno      = 0x5 <ASN1_INTEGER[5]>
    msgType   = 'AS-REP' 0xb <ASN1_INTEGER[11]>
    \padata    \
    |###[ PADATA ]###
    |  padataType= 'PA-ETYPE-INFO2' 0x13 <ASN1_INTEGER[19]>
    |  \padataValue\
    |   |###[ ETYPE_INFO2 ]###
    |   |  \seq       \
    |   |   |###[ ETYPE_INFO_ENTRY2 ]###
    |   |   |  etype     = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |   |   |  salt      = <ASN1_GENERAL_STRING[b'DOMAIN.LOCALuser1']>
    |   |   |  s2kparams = None
    crealm    = <ASN1_GENERAL_STRING[b'DOMAIN.LOCAL']>
    [...]
>>> res.sessionkey.toKey()
<Key 18 (32 octets)>

Low-level

Decrypt kerberos packets

Kerberos packets contain encrypted content, let’s take the following packet:

>>> pkt = Ether(b"RT\x00iX\x13RT\x00!l+\x08\x00E\x00\x01]\xa7\x18@\x00\x80\x06\xdc\x83\xc0\xa8z\x9c\xc0\xa8z\x11\xc2\t\x00XT\xf6\xab#\x92\xc2[\xd6P\x18 \x14\xb6\xe0\x00\x00\x00\x00\x011j\x82\x01-0\x82\x01)\xa1\x03\x02\x01\x05\xa2\x03\x02\x01\n\xa3c0a0L\xa1\x03\x02\x01\x02\xa2E\x04C0A\xa0\x03\x02\x01\x12\xa2:\x048HHM\xec\xb0\x1c\x9bb\xa1\xca\xbf\xbc?-\x1e\xd8Z\xa5\xe0\x93\xba\x83X\xa8\xce\xa3MC\x93\xaf\x93\xbf!\x1e'O\xa5\x8e\x81Hx\xdb\x9f\rz(\xd9Ns'f\r\xb4\xf3pK0\x11\xa1\x04\x02\x02\x00\x80\xa2\t\x04\x070\x05\xa0\x03\x01\x01\xff\xa4\x81\xb70\x81\xb4\xa0\x07\x03\x05\x00@\x81\x00\x10\xa1\x120\x10\xa0\x03\x02\x01\x01\xa1\t0\x07\x1b\x05win1$\xa2\x0e\x1b\x0cDOMAIN.LOCAL\xa3!0\x1f\xa0\x03\x02\x01\x02\xa1\x180\x16\x1b\x06krbtgt\x1b\x0cDOMAIN.LOCAL\xa5\x11\x18\x0f20370913024805Z\xa6\x11\x18\x0f20370913024805Z\xa7\x06\x02\x04p\x1c\xc5\xd1\xa8\x150\x13\x02\x01\x12\x02\x01\x11\x02\x01\x17\x02\x01\x18\x02\x02\xffy\x02\x01\x03\xa9\x1d0\x1b0\x19\xa0\x03\x02\x01\x14\xa1\x12\x04\x10WIN1            ")
>>> pkt[TCP].payload.show()
###[ KerberosTCPHeader ]###
len       = 305
###[ Kerberos ]###
    \root      \
    |###[ KRB_AS_REQ ]###
    |  pvno      = 0x5 <ASN1_INTEGER[5]>
    |  msgType   = 'AS-REQ' 0xa <ASN1_INTEGER[10]>
    |  \padata    \
    |   |###[ PADATA ]###
    |   |  padataType= 'PA-ENC-TIMESTAMP' 0x2 <ASN1_INTEGER[2]>
    |   |  \padataValue\
    |   |   |###[ EncryptedData ]###
    |   |   |  etype     = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |   |   |  kvno      = None
    |   |   |  cipher    = <ASN1_STRING[b"HHM\xec\xb0\x1c\x9bb\xa1\xca\xbf\xbc?-\x1e\xd8Z\xa5\xe0\x93\xba\x83X\xa8\xce\xa3MC\x93\xaf\x93\xbf!\x1e'O\xa5\x8e\x81Hx\xdb\x9f\rz(\xd9Ns'f\r\xb4\xf3pK"]>
    |   |###[ PADATA ]###
    |   |  padataType= 'PA-PAC-REQUEST' 0x80 <ASN1_INTEGER[128]>
    |   |  \padataValue\
    |   |   |###[ PA_PAC_REQUEST ]###
    |   |   |  includePac= True <ASN1_BOOLEAN[-1]>
    |  \reqBody   \
    |   |###[ KRB_KDC_REQ_BODY ]###
    |   |  kdcOptions= forwardable, renewable, canonicalize, renewable-ok <ASN1_BIT_STRING[0100000010...0000010000]=b'@\x81\x00\x10' (0 unused bit)>
    |   |  \cname     \
    |   |   |###[ PrincipalName ]###
    |   |   |  nameType  = 'NT-PRINCIPAL' 0x1 <ASN1_INTEGER[1]>
    |   |   |  nameString= [<ASN1_GENERAL_STRING[b'win1$']>]
    |   |  realm     = <ASN1_GENERAL_STRING[b'DOMAIN.LOCAL']>
    |   |  \sname     \
    |   |   |###[ PrincipalName ]###
    |   |   |  nameType  = 'NT-SRV-INST' 0x2 <ASN1_INTEGER[2]>
    |   |   |  nameString= [<ASN1_GENERAL_STRING[b'krbtgt']>, <ASN1_GENERAL_STRING[b'DOMAIN.LOCAL']>]
    |   |  from      = None
    |   |  till      = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |   |  rtime     = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |   |  nonce     = 0x701cc5d1 <ASN1_INTEGER[1880933841]>
    |   |  etype     = [0x12 <ASN1_INTEGER[18]>, 0x11 <ASN1_INTEGER[17]>, 0x17 <ASN1_INTEGER[23]>, 0x18 <ASN1_INTEGER[24]>, -0x87 <ASN1_INTEGER[-135]>, 0x3 <ASN1_INTEGER[3]>]
    |   |  \addresses \
    |   |   |###[ HostAddress ]###
    |   |   |  addrType  = 'NetBios' 0x14 <ASN1_INTEGER[20]>
    |   |   |  address   = <ASN1_STRING[b'WIN1            ']>
    |   |  encAuthorizationData= None
    |   |  additionalTickets= None

You likely want to decrypt pkt.root.padata[0].padataValue which is an EncryptedData packet. To do so, we need the Key class.

>>> from scapy.libs.rfc3961 import Key, EncryptionType
>>> enc = pkt[Kerberos].root.padata[0].padataValue
>>> k = Key(EncryptionType.AES256, key=hex_bytes("7fada4e566ae4fb270e2800a23ae87127a819d42e69b5e22de0ddc63da80096d"))

The first parameter of the Key constructor is a value from EncryptionType, in this case EncryptionType.AES256. This is the same value than enc.etype.val, which allows to know which key to use.

We can then proceed to perform the decryption:

>>> enc.decrypt(k)
<PA_ENC_TS_ENC  patimestamp=2022-07-15 17:18:47 UTC <ASN1_GENERALIZED_TIME['20220715171847Z']> pausec=0x9a4db <ASN1_INTEGER[632027]> |>

Compute Kerberos keys

Note

Encryption for Kerberos 5 is defined in RFC3961

You may want to compute a Kerberos key from a password + salt. There is an API for that described in RFC3961 as “string-to-key”. Our implementation is a class method as follow:

Key.string_to_key(etype, string, salt, params=None)

Compute the kerberos key for a certain encryption type.

Parameters

  • etype (int) – The EncryptionType to use. May be any value from EncryptionType

  • string (bytes) – The “string” bytes to use. This is the user password in almost all well-used cases. They must be passed as bytes.

  • salt (bytes) – The salt bytes to use. What value to use depends if you are considering a MACHINE account or a USER account, for the latter, it’s just the concatenation of the principal's realm and name components, in order, with no separators. (RFC4120 sect 4)

  • params (bytes) – The opaque “parameter” used by string-to-key. The RFC defines this field in a very general manner but it is basically only used in AES, in which it is the iteration count as a big-endian int (struct.pack(">L", 4096) by default)

Let’s run a few examples:

>>> # Get the AES256 key for User1@DOMAIN.LOCAL with "Password1"
>>> from scapy.libs.rfc3961 import Key, EncryptionType
>>> Key.string_to_key(EncryptionType.AES256, b"Password1", b"DOMAIN.LOCALUser1")
>>> print(_.key)
b'm\x07H\xc5F\xf4\xe9\x92\x05\xe7\x8f\x8d\xa7h\x1dN\xc5R\n\xe4\x81UCr\x0c*d|\x1a\xe8\x14\xc9'

Note

The following example is from https://datatracker.ietf.org/doc/html/rfc3962#appendix-B

>>> # Get the AES128 key for raeburn@ATHENA.MIT.EDU with "password", with an iteration count of 1200
>>> k = Key.string_to_key(EncryptionType.AES128, b"password", b"ATHENA.MIT.EDUraeburn", struct.pack(">L", 1200))
>>> print(bytes_hex(k.key))
b'4c01cd46d632d01e6dbe230a01ed642a'

Decrypt FAST

Note

Have a look at RFC6113 for Kerberos FAST

Let’s take a Kerberos AS-REQ packet with FAST armoring (RFC6113):

../_images/as_req_fast.png

FAST armoring in AS-REQ. Courtesy of Aurélien Bordes

>>> pkt = Ether(hex_bytes(b'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'))
>>> pkt[TCP].payload.show()
###[ KerberosTCPHeader ]###
    len       = 2154
###[ Kerberos ]###
    \root      \
    |###[ KRB_AS_REQ ]###
    |  pvno      = 0x5 <ASN1_INTEGER[5]>
    |  msgType   = 'AS-REQ' 0xa <ASN1_INTEGER[10]>
    |  \padata    \
    |   |###[ PADATA ]###
    |   |  padataType= 'PA-FX-FAST' 0x88 <ASN1_INTEGER[136]>
    |   |  \padataValue\
    |   |   |###[ PA_FX_FAST_REQUEST ]###
    |   |   |  \armoredData\
    |   |   |   |###[ KrbFastArmoredReq ]###
    |   |   |   |  \armor     \
    |   |   |   |   |###[ KrbFastArmor ]###
    |   |   |   |   |  armorType = 'FX_FAST_ARMOR_AP_REQUEST' 0x1 <ASN1_INTEGER[1]>
    |   |   |   |   |  \armorValue\
    |   |   |   |   |   |###[ KRB_AP_REQ ]###
    |   |   |   |   |   |  pvno      = 0x5 <ASN1_INTEGER[5]>
    |   |   |   |   |   |  msgType   = 'AP-REQ' 0xe <ASN1_INTEGER[14]>
    |   |   |   |   |   |  apOptions =  <ASN1_BIT_STRING[0000000000...0000000000]=b'\x00\x00\x00\x00' (0 unused bit)>
    |   |   |   |   |   |  \ticket    \
    |   |   |   |   |   |   |###[ KRB_Ticket ]###
    |   |   |   |   |   |   |  tktVno    = 0x5 <ASN1_INTEGER[5]>
    |   |   |   |   |   |   |  realm     = <ASN1_GENERAL_STRING[b'DOM1.LOCAL']>
    |   |   |   |   |   |   |  \sname     \
    |   |   |   |   |   |   |   |###[ PrincipalName ]###
    |   |   |   |   |   |   |   |  nameType  = 'NT-SRV-INST' 0x2 <ASN1_INTEGER[2]>
    |   |   |   |   |   |   |   |  nameString= [<ASN1_GENERAL_STRING[b'krbtgt']>, <ASN1_GENERAL_STRING[b'DOM1.LOCAL']>]
    |   |   |   |   |   |   |  \encPart   \
    |   |   |   |   |   |   |   |###[ EncryptedData ]###
    |   |   |   |   |   |   |   |  etype     = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |   |   |   |   |   |   |   |  kvno      = 0x2 <ASN1_INTEGER[2]>
    |   |   |   |   |   |   |   |  cipher    = <ASN1_STRING[b'\xac\xc8\xb7g\x1c\rPR/\x1a\x8d\x84R\xceE\n\xce\xb4\x0f\xff\x02)\xe8\xeeTk\xcc\xf1Q.Hw\xef\x93\xdd\xe4eYR`\xa6\xa5\xa8\xe8^\xa3\x86\x00\xce\x8d\xff}Q\x0f<tN,C\xeb\x9d1\x87\xd68\xf7\x16\xc2\x9bnz\xa9\xeb@}\xe2\x8d\x01a\xf4\x90\x13\x96n\xda\n\x16\x1f\xf1t\xda\xd4.z\xa5\x00\xcf\xe2\x98T\x12\x15D\x80\x13\xff\xe4\x88;k\x11f\xf9\x08\xf5\r\xe1)H\x7f\xe7\x7f\xff\x87O\xd4\x10,\xdc\xce\x8d\xb8\xdb\xeb\x8d\xa0/\x08\xcc\x88\xb3y\x0c\xda\xd5\xecI\x99Y\xc7\xe7\x9do\xef\x10}\x1e\x17\xce\x80\xcc=\xf0P\xb7\xe7\xa1\xc3\x1f\'\x8eO\xd4\xea\x95#\xc9P\x87o\x17K\xe3c#O\x84\x95\xb9U\r\xe1V\x0b\xa1}\xae\xaf\xbf\x13?x\x99\x10S\xd9)\xad?\xd6h2}B(\x8ee\x81g\x1d\xaa\xef\x90\x86\x82\xee(.\x17\xc3\x1d\x8f\x8b\xb5]\'\xfc\xe1U\xee.\x84\xa2\xff\x8b\xc9`\x08\x91\xbe\x15\xe6\xed\xe3\xe1\xbb\xd2t*z\xf8\xb0\xa3,H\x97<\x9e7v\xa6\x96G\xba\xb1\x15\x92ulZ\x15\xb9\x10\x1c9.\xfa5\xd0\x00\xab\xb3\xda\xbc\xcd\x97\xe6D&\xe3\xfd\x8dG\xe0\xe3i\xc8;S\x91\xf3\x89G\xd56\xd3Q\xc0a\x08\x1deN\xef\x1a8a\xcd\xb2\xea+\xc4\x82"\xb4P\xd1\xb7\xd0\x9c\x06pI;\xcc\xc6\r\xfc\xaa\\\xfeF\xfdP\xad\xf8\xe3\x88 JF\x91\xdc_\x0c=\xba\xe0\xb4\xdaj\xc2\xddx\x1f\x14\x9aDH@\xaa\xa3\xa3\xc3\xbe\xfbZ\\\x04\xee\x04\x05\xba\xedf\xaf\xcf\x9b\x98\x8d\x10\xea\x14\xa9U\xf4=\xf7\x94e\xe6\xfc\x02\xa1+\xce8p\x98\x89P\xf1\xabH\xe1\xa4\xf8v\xf3Qg\x1cPa\xe69\x9ac\xcb\x04y\xf7\xbd\x01}\xfd\x9b\xc5\xbe\x19/\xafmO\x11\xe6\xee`\x03\x93>\xea\xf62\xf0\x05lL\x1c\xcd\x18=yw\xcf\xca\x85A\x9f\xe5\xb09gD\x19\xd8\x02\x06\x8ey,\x95v\xae*\x88\xbf\xbe\xb1\xf5\x92s"g\x82\xc6\xef\xb2\x88q}\x8fzK\xc3\xbfLi\x7f\xca\xc1\xad\xc1\x82\x9f\n\x91O%Y\xb2x\xcc\xad\xd1\x08\xeb\x87\xa1\x1d\xac\xc8\x8eC\x02\xe9\xafbtt\xe5qq\x19+\x94\xc6\xb3X\xf8\xf9\x8e0\x85\x96!]/\xb9\xd9\xc2\xb4\x9cL\xbe\xdc\xb4?\xc21\xb8o\x04\x93\xd5k\x82\x96,\xf38:\x84\xf8\x92,+\x99\xf8\xfa\x8f\xdd\x85y{\t\xa6\xe6\x0fr\x00|\x03y\x98\x8b\xe2\xff\x1c\xfc\x16\xf2\x13\x00\xc1\xb4\xb7\x84\x17@\x05\xa9\x18_v\x0eh\xef\x94\xb98N\xb2M\xec\xee1\xb6=\x1b\x92\'\x8c\xd7[\x85\xd4\xd8\x0cN\x830e3\xa9\xd9Z\xa6 |\xbf\xbe\xb0\x97\nA\xc4J\xbaY\x83\x9f\x00y#\xec\xd8\xff\r\xe81I\x90\xa45\xdb\xeaM\xed\xbe\xe1o\xafZ\xb2\xbe\x9f\x96\xd6\x91\xcf\xa9\x83\xa6\xc8C\xbd\x18?\x84\xc1\xb4\x99\x8a>\xaa\x90|\xaek\x82\xb0\xae\x83c\xf3\xed\xd8\xcb\x03\xd3\xc9\xc6\x0f\xf5Z\x84\xd8\xa2\x92\xea U_\xbdl\xe5\xadJ\xd7\xa6\xb4\xbc[\xff.\x02\xc4w\xa7\xa8\xa9\x8dZ8}8\x9c\xaa\x17,@\x0b\x15\x1d\x95\x87\x1b*\xa1j\x04\r\xc7\x1a\x9b\xe5\xf0wK\x06\xa5\xca\x87gL\xcbA\t\xa2\xc4\x1d\xb9\xe3\x16\x07\x04!\x8a\xd4\x95\xd0u\x11\x94\xfb\xefK\xec\xaeM{\xe2K\x9d\x96\x8d\xa5\x92%j+"\xcfrN\x98\x9eq\xa6\r\x06\x03\xb5\x9b\xeb\xd4u(_y7\x94\xb7\xa1\x8a\xf4\x9a+hg\x0e:bG\xc4S\'N5\xc8c\xa1kP#\xc6\xc9FY\xe2Z\xbb\'\xc7`\xf9\x89\xac\x0b\xbf\x9a[\x12]\x0e\xa3O\xb02%\xcc\x93\xd5\xb8\xb6\x82\x9e\x90h\x83\xeev\xcf\x8e\xe6\x1d\xfa\xccH\x8e\x8d\xc5\xcb\xc8\xba\x97\x05\xa9\xe9\x15\xa6\x8f\x83\x8229O\x97\xfb\x1a\xacJ*\x90\xfe\x17\xd4o\x9cQ\x94j+\xf9Y\x8d\xf7\xf5\xb5\xe7\xeei*x\x86\x0e\xea<\xeft\x8a[\xe3e)"\x8e@\xb4\xae\xc8>\xbc\x8b\xb1Av\xa4\xc5e\xb0e\x00\xe9Qr)\xb84\x0cU\x81!\x01\xdb\xbck\xeei<5\x870\x82\xa5\xa1\xa5;5\xcf5\t\x19=M\xc5\x17\\\x93`\xa0\r\xa7\x16\x92\xba [2d\xae\xcc\x9e\xcc\x8b\xca1\xfe\xc4>\xfc\x87\x01B;\xb4\x84\xf6\xf2\x16\x99C\x9d\xd3\x0fq"\x8f\x16\xea\xab\x96\xb7\xde5Gr\x1d\x165\xbb\xfePg\x89\x00\xac7\x8aIX\xb6\xc3Id\xf3\xe0\xdc\x848\x80\xdb\xdeW\xfbJv\xab\x85\xeb\xa2\xb1\x90\xbf\xda\xef\xc7\xba\x17\xe1\t\xf89I;\x0f-o\xc7\xea\x17@;\xeb\xe0o(\t1L\xa5\x14`oTf\x80\x826N\xd6u \x19\xf2~\x1d\xf7O\x93\xfc\xf1\xc2V0\xa2\x97\x13\xa8\x9dJ\x99\x8cDK\xc9\x12y\xc6\xfcf\xe0\xaa]\xecr\xbe1n\x11`\xcf\x9f\x90\xd5\x91\\FKk\xfe\xc5!n\x90\x1b\xe4rm\xb5\x96\xa1WEQ\x1ccsji\xac\x9e\xcb\x9e\x86`\x1cc\x1bI\x92e<2\x0ei\x83V/\xa6\x13\x13E`\xcb`f!\xe9f\x1a\xc5\x96\x13\x13\xeep\x86\x8a\xb4\x8d`\x10\x17=\x8a\x96\xff\xfd\xb2\xba\xf4\xaf\xe1\x8c\x84m?\xedo0\xb9\xa8\t\xd7.dw5\xfcSn\xde\xc5C\xab\xc22H\r(f\x03\x95']>
    |   |   |   |   |   |  \authenticator\
    |   |   |   |   |   |   |###[ EncryptedData ]###
    |   |   |   |   |   |   |  etype     = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |   |   |   |   |   |   |  kvno      = None
    |   |   |   |   |   |   |  cipher    = <ASN1_STRING[b'\x12s\xd5\xafa\xadBmQ\xd0u~\x89y\x17\xca\xebo\xc1\xb6\x95\x05T\xe8\xd7P\xf9]\'\xf4D\xe3\xaa\xf7\xae\x0b\xf4Y[^\x90m\x96\x82\xdb\xde\xed\xcfn\xb4*\x84\xab\x80\x92\x99{x?Wq\x01\'"\x81e\xde\xeb,\xe5\xe0\x9e-\xdcqU]\xc3\x19p\xa81-\x88\x8b\x8a\xe7f8 \x98\'mb\xb4\xbdv\xf3L\xbc\x88\x9e$\xadT\x05\xec\x03|\xebrO\xdbq\xfe$\x7f\xe2\xa4\x14\xa07\xed3\xc7\x96\xf4G_\xcf\xb5\x99>\xed\x14{mc\xd7@\xd5\x8d\xa5\xb0']>
    |   |   |   |  checksumtype= 'HMAC-SHA1-96-AES256' 0x10 <ASN1_INTEGER[16]>
    |   |   |   |  checksum  = <ASN1_STRING[b'\xa7_&\xdb#\x01\xc6\x97\x0f\xeb\xa4R']>
    |   |   |   |  \encFastReq\
    |   |   |   |   |###[ EncryptedData ]###
    |   |   |   |   |  etype     = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |   |   |   |   |  kvno      = None
    |   |   |   |   |  cipher    = <ASN1_STRING[b'<\xaf4\xec\xef\xd8Lxg\x03\xc2\x009\xdea\xbc\x01\xeb\xed\x9b\xe7\xe5\x1c\x90\xa5\x82\xfe\xc8Rik\xf9/\xd1e\xcd[^\xf0\xf9\xb8\xed\xb6f\xc9\xcc\xa5i\r6N\\j\xd6\x9e}[\xc7\xe0Uuz\xaab\x06B\x8a0%$\x14M]\x97\xcc\x0bd\xdb\x133PE\x03\x91q\xed\x1f\r\x11\x1c\xa1\xbdFQ\xeb\xca=t\xdb\x02\x9e\\m<\x7f\x86\x00\xc4NU\xb1L\xd3\xc7\xf6\xa1\\\x913@\x0eBU\xd7\x1f#{\xf2\x88\xc1\x86\x13|\xd0J_,\xab\xba1f\xde[\xf1\x11\x90\xa2\xe5\x96.M\xbb\xfb\x98\x01\xe3\xbes\xed\xe5\xa56\xeb\'\xa0\x86\xb6D\xf1"E\x19\x84Y\xc0c\xb8\xec\xba"\x8e\x1f\x92\t\xe0Z[\xcb\xb3\x9a\x12e\x1e\x1048\xeey\x98\xe6f\xd8b\x88\x12\xfa4\xbc\x07\xf4\xc4\xd0\xa4\xd8o\xe2\x07\x12\x8d\xe3~\x1f\xfd\x16\x9aL\xb8y\xcb[\x9d\xb8\xf9\xc3\xe8aC\xbf\xd44\t\xcaG\xe9\x0f;\xc8H\xa1\x83\x8f\xcer\t\xf5r\x96\xe4Ic\xa2\xd1\xe3\xd4']>
    |  \reqBody   \
    |   |###[ KRB_KDC_REQ_BODY ]###
    |   |  kdcOptions= forwardable, renewable, canonicalize, renewable-ok <ASN1_BIT_STRING[0100000010...0000010000]=b'@\x81\x00\x10' (0 unused bit)>
    |   |  \cname     \
    |   |   |###[ PrincipalName ]###
    |   |   |  nameType  = 'NT-PRINCIPAL' 0x1 <ASN1_INTEGER[1]>
    |   |   |  nameString= [<ASN1_GENERAL_STRING[b'adm-r-xmartin']>]
    |   |  realm     = <ASN1_GENERAL_STRING[b'DOM1']>
    |   |  \sname     \
    |   |   |###[ PrincipalName ]###
    |   |   |  nameType  = 'NT-SRV-INST' 0x2 <ASN1_INTEGER[2]>
    |   |   |  nameString= [<ASN1_GENERAL_STRING[b'krbtgt']>, <ASN1_GENERAL_STRING[b'DOM1']>]
    |   |  from      = None
    |   |  till      = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |   |  rtime     = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |   |  nonce     = 0x3f58a7a0 <ASN1_INTEGER[1062774688]>
    |   |  etype     = [0x12 <ASN1_INTEGER[18]>, 0x11 <ASN1_INTEGER[17]>, 0x17 <ASN1_INTEGER[23]>, 0x18 <ASN1_INTEGER[24]>, -0x87 <ASN1_INTEGER[-135]>, 0x3 <ASN1_INTEGER[3]>]
    |   |  \addresses \
    |   |   |###[ HostAddress ]###
    |   |   |  addrType  = 'NetBios' 0x14 <ASN1_INTEGER[20]>
    |   |   |  address   = <ASN1_STRING[b'SRV             ']>
    |   |  encAuthorizationData= None
    |   |  additionalTickets= None

There are 3 encrypted payloads:

  • pkt.root.padata[0].padataValue.armoredData.armor.armorValue.ticket.encPart, encrypted using the KRBTGT

  • pkt.root.padata[0].padataValue.armoredData.armor.armorValue.authenticator, encrypted using the ticket session key (that the clients gets from the first AS-REQ, and that that is also included in tickets for the server to use)

  • pkt.root.padata[0].padataValue.armoredData.encFastReq, encrypted using using the armor key

We have the krbtgt for this demo:

>>> from scapy.libs.rfc3961 import Key, EncryptionType
>>> krbtgt_hex = "ac67a63d7155791fe31dace230ab516e818c453dfdbd44cbe691b240725c4907"
>>> krbtgt = Key(EncryptionType.AES256, key=hex_bytes(krbtgt_hex))

We can therefore decrypt the first payload:

>>> enc = pkt.root.padata[0].padataValue.armoredData.armor.armorValue.ticket.encPart
>>> encticketpart = enc.decrypt(krbtgt)
>>> encticketpart.show()
###[ EncTicketPart ]###
    flags     = forwardable, renewable, initial, pre-authent <ASN1_BIT_STRING[0100000011...0000000000]=b'@\xe1\x00\x00' (0 unused bit)>
    \key       \
    |###[ EncryptionKey ]###
    |  keytype   = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |  keyvalue  = <ASN1_STRING[b'\xe3\xa2\x0f\x8e\xb2\xe1*\xe0\x7f\x86\xcc\x88\xe6,\x08>B\xd8)m/G\x82B;\x9f+\x86\xcd\xcd\xf4\x05']>
    crealm    = <ASN1_GENERAL_STRING[b'DOM1.LOCAL']>
    \cname     \
    |###[ PrincipalName ]###
    |  nameType  = 'NT-PRINCIPAL' 0x1 <ASN1_INTEGER[1]>
    |  nameString= [<ASN1_GENERAL_STRING[b'SRV$']>]
    \transited \
    |###[ TransitedEncoding ]###
    |  trType    = 0x0 <ASN1_INTEGER[0]>
    |  contents  = <ASN1_STRING[b'']>
    authtime  = 2022-07-12 23:02:25 UTC <ASN1_GENERALIZED_TIME['20220712230225Z']>
    starttime = 2022-07-12 23:02:25 UTC <ASN1_GENERALIZED_TIME['20220712230225Z']>
    endtime   = 2022-07-13 09:02:25 UTC <ASN1_GENERALIZED_TIME['20220713090225Z']>
    renewTill = 2022-07-19 23:02:25 UTC <ASN1_GENERALIZED_TIME['20220719230225Z']>
    addresses = None
[...]

We can see the ticket session key in there, let’s retrieve it and build a Key object:

Note

We use the .toKey() function in the EncryptedKey type which is a shorthand for Key(<keytype>, key=<keyvalue>)

>>> ticket_session_key = encticketpart.key.toKey()
>>> ticket_session_key.key
b'\xe3\xa2\x0f\x8e\xb2\xe1*\xe0\x7f\x86\xcc\x88\xe6,\x08>B\xd8)m/G\x82B;\x9f+\x86\xcd\xcd\xf4\x05'

We can now decrypt the second payload:

>>> enc = pkt.root.padata[0].padataValue.armoredData.armor.armorValue.authenticator
>>> authenticator = enc.decrypt(ticket_session_key)
>>> authenticator.show()
###[ KRB_Authenticator ]###
    authenticatorPvno= 0x5 <ASN1_INTEGER[5]>
    crealm    = <ASN1_GENERAL_STRING[b'DOM1.LOCAL']>
    \cname     \
    |###[ PrincipalName ]###
    |  nameType  = 'NT-PRINCIPAL' 0x1 <ASN1_INTEGER[1]>
    |  nameString= [<ASN1_GENERAL_STRING[b'SRV$']>]
    checksumtype= 0x0 <ASN1_INTEGER[0]>
    checksum  = <ASN1_STRING['']>
    cusec     = 0x3c <ASN1_INTEGER[60]>
    ctime     = 2022-07-12 23:54:37 UTC <ASN1_GENERALIZED_TIME['20220712235437Z']>
    \subkey    \
    |###[ EncryptionKey ]###
    |  keytype   = 'AES-256' 0x12 <ASN1_INTEGER[18]>
    |  keyvalue  = <ASN1_STRING[b'%\xa4n\xe1\xd0\xf5\x8d\xc4\x8d\xecv\xe8\x9c\xd3\xc9\xee\x1bu\xc9\xa5\xa6\xf8\x83f\x98\xa1\xd9\xe7*I\x9b\xf8']>
    seqNumber = 0x0 <ASN1_INTEGER[0]>
    encAuthorizationData= None

Again, we see inside this the subkey that is used to compute the armor key. We get it:

>>> subkey = authenticator.subkey.toKey()
>>> subkey.key
b'%\xa4n\xe1\xd0\xf5\x8d\xc4\x8d\xecv\xe8\x9c\xd3\xc9\xee\x1bu\xc9\xa5\xa6\xf8\x83f\x98\xa1\xd9\xe7*I\x9b\xf8'

Following RFC6113 sect 5.4.1.1, we can now compute the armor key using:

>>> from scapy.libs.rfc3961 import KRB_FX_CF2
>>> armorkey = KRB_FX_CF2(subkey, ticket_session_key, b"subkeyarmor", b"ticketarmor")
>>> print(armorkey.key)
b'\x9f\x18L]I\x16\xd0\xe5\xa6\xd9\x92+\xbf\xbc\xe0\n\xd1\xcb6\xf3\xd1.C\xc2\xdcp\xf0H(\x99\x14\x80'

That we can now use to decrypt the last payload:

>>> enc = pkt.root.padata[0].padataValue.armoredData.encFastReq
>>> krbfastreq = enc.decrypt(armorkey)
>>> krbfastreq.show()
###[ KrbFastReq ]###
    fastOptions=  <ASN1_BIT_STRING[0000000000...0000000000]=b'\x00\x00\x00\x00' (0 unused bit)>
    \padata    \
    |###[ PADATA ]###
    |  padataType= 'PA-PAC-REQUEST' 0x80 <ASN1_INTEGER[128]>
    |  \padataValue\
    |   |###[ PA_PAC_REQUEST ]###
    |   |  includePac= True <ASN1_BOOLEAN[-1]>
    |###[ PADATA ]###
    |  padataType= 'PA-PAC-OPTIONS' 0xa7 <ASN1_INTEGER[167]>
    |  \padataValue\
    |   |###[ PA_PAC_OPTIONS ]###
    |   |  options   = Claims <ASN1_BIT_STRING[1000000000...0000000000]=b'\x80\x00\x00\x00' (0 unused bit)>
    \reqBody   \
    |###[ KRB_KDC_REQ_BODY ]###
    |  kdcOptions= forwardable, renewable, canonicalize, renewable-ok <ASN1_BIT_STRING[0100000010...0000010000]=b'@\x81\x00\x10' (0 unused bit)>
    |  \cname     \
    |   |###[ PrincipalName ]###
    |   |  nameType  = 'NT-PRINCIPAL' 0x1 <ASN1_INTEGER[1]>
    |   |  nameString= [<ASN1_GENERAL_STRING[b'adm-r-xmartin']>]
    |  realm     = <ASN1_GENERAL_STRING[b'DOM1']>
    |  \sname     \
    |   |###[ PrincipalName ]###
    |   |  nameType  = 'NT-SRV-INST' 0x2 <ASN1_INTEGER[2]>
    |   |  nameString= [<ASN1_GENERAL_STRING[b'krbtgt']>, <ASN1_GENERAL_STRING[b'DOM1']>]
    |  from      = None
    |  till      = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |  rtime     = 2037-09-13 02:48:05 UTC <ASN1_GENERALIZED_TIME['20370913024805Z']>
    |  nonce     = 0x3f58a7a0 <ASN1_INTEGER[1062774688]>
    |  etype     = [0x12 <ASN1_INTEGER[18]>, 0x11 <ASN1_INTEGER[17]>, 0x17 <ASN1_INTEGER[23]>, 0x18 <ASN1_INTEGER[24]>, -0x87 <ASN1_INTEGER[-135]>, 0x3 <ASN1_INTEGER[3]>]
    |  \addresses \
    |   |###[ HostAddress ]###
    |   |  addrType  = 'NetBios' 0x14 <ASN1_INTEGER[20]>
    |   |  address   = <ASN1_STRING[b'SRV             ']>
    |  encAuthorizationData= None
    |  additionalTickets= None

Encryption

A encrypt() function exists in the Key object in order to do the opposite of decrypt().

For instance, during pre-authentication, encode PA-ENC-TIMESTAMP:

>>> from datetime import datetime
>>> from scapy.libs.rfc3961 import Key, EncryptionType
>>> # Create the PADATA layer with its EncryptedValue
>>> pkt = PADATA(padataType=0x2, padataValue=EncryptedData())
>>> # Compute the key
>>> key = Key.string_to_key(EncryptionType.AES256, b"Password1", b"DOMAIN.LOCALUser1")
>>> now_time = datetime.now(timezone.utc).replace(microsecond=0)  # Current time with no milliseconds
>>> # Encrypt
>>> pkt.padataValue.encrypt(key, PA_ENC_TS_ENC(patimestamp=ASN1_GENERALIZED_TIME(now_time)))
>>> pkt.show()
###[ PADATA ]###
    padataType= 2
    \padataValue\
    |###[ EncryptedData ]###
    |  etype     = 18
    |  kvno      = 0x0 <ASN1_INTEGER[0]>
    |  cipher    = b"\xc1\x9a\xaf\x89V\x16\x82\xb6\x9a\xcb\x15[\xaf\xed\xd9\xfc\x04\xbf\x18\xd4&\x91\xb3\xcf~tEk,\x98m\xee\xa4O\x05=\x11b\xe05\xca\x92+80\x99\xb1'~\x8d\xdbtz\xa8"
